Furnace Parts Forged Stainless Steel Bar GB Standard 100% UT Passed

    Buy cheap Furnace Parts Forged Stainless Steel Bar GB Standard 100% UT Passed from wholesalers

    Buy cheap Furnace Parts Forged Stainless Steel Bar GB Standard 100% UT Passed from wholesalers
    • Buy cheap Furnace Parts Forged Stainless Steel Bar GB Standard 100% UT Passed from wholesalers
    • Buy cheap Furnace Parts Forged Stainless Steel Bar GB Standard 100% UT Passed from wholesalers

    Furnace Parts Forged Stainless Steel Bar GB Standard 100% UT Passed

    Ask Lasest Price
    Brand Name : UST
    Model Number : ASTM 310 / 310S
    Certification : ISO 9001:2008
    Price : USD 1250-3500 / Metric Ton
    Payment Terms : L/C, T/T, D/A, D/P
    Supply Ability : 1000 Metric Tons per Month
    Delivery Time : 15-35 days
    • Product Details
    • Company Profile

    Furnace Parts Forged Stainless Steel Bar GB Standard 100% UT Passed

    INTRODUCTION


    Alloy 310 is an austenitic stainless steel that combines excellent high temperature properties with good ductility and weldability. It is typically used for elevated temperature applications as its high chromium and nickel content provide solid corrosion resistance, excellent resistance to oxidation, and superior strength in temperatures up to 2100°F. Due to its high chromium and nickel content, it is superior to 304 or 309 stainless in most environments.


    APPLICATIONS


    The higher alloyed stainless steels generally have excellent strength at elevated temperatures along with outstanding resistance to creep deformation and environmental attack. Therefore, Alloy 310 is used widely in industries such as heat treatment and chemical processing. Some examples include:

    • Furnace Parts
    • Oil Burner Parts
    • Heat Exchangers
    • Welding Filler Wire and Electrodes
    • Annealing Covers
    • Combustion Tubes
    • Fire Box Sheets
    Steel Grade310 / 310SApplicationWidely used in industries such as heat treatment and chemical processing
    ShapeRound BarStandardGB, ASTM, DIN,JIS
    DimensionΦ4-800 mm; length below 10mSurfaceBlack, Bright, Polished, Peeled
    TechniqueCold drawn; Hot rolled; ForgedUltrasonic Test100% UT Passed

    DELIVERY CONDITIONS


    Diameter (mm)
    Cold drawn4-60
    Peeled30-100
    Grinded4-600
    Turned130-800
    Hot Rolled20-280
    Hot Forged130-800

    EQUIVALENT GRADES OF ASTM 310 / 310S

    • ASTM/ASME: UNS S31000 / S31008
    • EURONORM: 1.4841 / 1.4845
    • DIN: X15CrNiSi25-21 / X8CrNi25-21

    CHEMICAL COMPOSITION (%)


    CSiMnPSCrNiMoCu
    310

    0.25

    0.75

    2.00

    0.045

    0.030

    24.00

    26.00

    19.00

    22.00

    0.75

    0.50

    310S

    0.08

    1.00

    2.00

    0.045

    0.030

    24.00

    26.00

    19.00

    22.00

    0.75

    0.50


    MECHANICAL PROPERTIES

    GradeTensile Strength ksi (min)Yield Strength 0.2% ksi (min)Elongation %Hardness (Brinell) MAXHardness (Rockwell B) MAX
    310/310S75304021795

    The difference between 310 and 310S


    ASTM 310 and ASTM 310S division key elements of the same; main difference is the size of the carbon content: ASTM 310 carbon content of <= 0.25%, while the carbon content in ASTM 310S <= 0.08%.ASTM 310S The S stands for the special treatment of the ASTM 310 stainless steel, mechanical properties superior to ASTM 310 stainless steel, therefore, ASTM 310S stainless steel temperature is higher than the ASTM 310 stainless steel.


    RESISTANCE

    Corrosion Resistance:

    • Provides excellent corrosion resistance
    • High chromium content allows for good aqueous corrosion resistance
    • Excellent resistance at normal temperatures and also has good resistance to oxidizing and carburizing atmospheres

    Heat Resistance:

    • Good resistance to oxidation in intermittent service in air at temperatures up to 1040°C and 1150°C in continuous service.
    • Good resistance to thermal fatigue and cyclic heating.
    • Widely used where sulphur dioxide gas is encountered at elevated temperatures.
    • Continuous use in 425-860°C range not recommended due to carbide precipitation, if subsequent aqueous corrosion resistance is needed
    • Generally used at temperatures starting from about 800 or 900°C – above the temperatures at which 304H and 321 are effective.

    PROCESSING


    Fabrication:

    • Commonly used in the heat treatment and process industries due to high temperature and corrosive environments
    • Often fabricated into complex structures
    • Roller-forms, stamps and draws readily
    • Because 310 work hardens, severe forming operations should be followed by an anneal

    Weldability:

    • Austenitic stainless steel is generally considered to be weldable
    • Generally considered to have weldability equivalent to 304 and 304L
    • Special consideration is needed to compensate for a higher coefficient of thermal expansion to avoid warping and distortion

    What we can offer?

    -We offer a wide range of steel products in a wide variety of dimensions and executions, according to the common international specifications or customize.

    -Machining and heat treatment are available.

    -Also, we advise you in choosing the right materials.


    Shape Available

    • Solid round bar
    • Flat bar
    • Square bar
    • Hexagon bar
    • Block
    • Plate
    • Sheet
    • Wire rod
    • Strip

    Our Advantages

    • High mechanical property and quenching, enable the surface share equal hardness after deal with it
    • Good polishing and low roughness
    • Making the heat-treatment to harden condition before using it
    • Competitive price
    • Fast production lead-time
    • All the material are inspected with 3 times to meet the highly standards
    • Pure steel quality & stable quality to be guarantee

    OUR AVAILABLE STAINLESS STEEL PRODUCTS ARE AS BELOW


    PAYMENT AND SHIPPING


    1. Both T/T and L/C will be acceptable

    2. Trade Terms: FOB, CIF, CFR

    3. The delivery will be in 10-15 days if have stock; For customized items, the delivery will be negotiated by both parties

    4. Shipping by sea freight from Shanghai Port (PRC) for Bulk orders, by airfreight or express for samples
