DIN 2391 Seamless Cold Rolled Steel Tube Alloy steel for Mechanical
Parts 4340
Introduction
Cold drawn seamless has closer dimensional tolerances, better surface finish and higher mechanical properties than corresponding grades of hot finished seamless.
Product
| 4340 cold rolled steel tube |
Process
| Cold rolled |
Shape
| Round |
Thickness
| 2-25mm |
O.D
| 10-150mm |
Length
| Random Length, Fixed Length, etc. |
| Standard | DIN 2391 Seamless Precison Steel Tubes BS6323 Specification for Seamless and Welded Steel Tubes for
Automobile, Mechanical and General Engineering Purposes ASTM A519 Standard Specification for Seamless Carbon and Alloy
Steel Mechanical Tubing |
Material
| 4340 |
| Package |
Standard Sea-worthy package , fixed by belt then loaded into
fumigated wooden box.
|
Type
| Seamless steel pipe. |
| Application | Automotive car exhaust. |
| Automotive car fuel pump shell. |
| Automobile Chassis. |
| General pipes connecting projects etc. |
| The occasion where the high accuracy, brightness, cleanness of the
tube are required. |
| Container Size | 20Gp - 2.352(width) *2.385 ( Height ) * 5.90 ( Inside length )
Meter |
| 40Gp - 2.352(width) *2.385 ( Height ) * 11.8 ( Inside length )
Meter |
| 40HQ - 2.352(width) *2.69 ( Width ) * 5.90 ( Inside length ) Meter |
| Export Region | America , Canada ,Japan , England , Saudi Arab , India , Singapore
, Korea , Australia , Brazil , Argentina , Mexico , Russia , Turkey
, Greece , France , Germany , Spain |
Payment terms
| T/T , L/C. |
Delivery time
| 5 days in stock , if not 15-35 days |
Port of shipment
| Shanghai port. |
MOQ
| 3 Ton |
Trade Terms
| FOB , CFR , CIF |
Dimension Tolerance
| I.D tolerance (mm) | O.D tolerance (mm) | I.D Roughness (µm) | Straightness (mm/meter) |
| H7-H9 | -/+0.5% | 0.10-0.80 | 0.2-0.80 |
Chemical composition(%)
| Grade | C | Si | Mn | P | S | Cr | Mo | Ni |
| 4340 | 0.38-0.43 | 0.15-0.35 | 0.60-0.80 | 0.040max | 0.040max | 0.70-0.90 | 0.20-0.30 | 1.65-2.00 |
End Shape
Beveled end , plain end, varnished, or adding plastic caps to
protect the two ends as per customer's requirements
Main Features
- No Oxidation Layer on the outer and inner walls;
- No Leakage under high pressure;
- No Crake under flating and flattening;
- No distortion after cold bending;
- High precision high cleanness;
- Excellent brightness
What we can offer?
-We offer a wide range of steel products in a wide variety of
dimensions and executions, according to the common international
specifications or customize.
-Machining and heat treatment are available.
-Also, we advise you in choosing the right materials.
Quality Assurance
Below inspection will be done in the production.
(1) ray detection---RT;
(2) ultrasonic testing---UT;
(3) Magnetic Particle Testing-MT;
(4) penetration testing-PT;
(5) eddy current flaw detection-ET
Package
In standard export packing and seaworthy material with hexagon shape bundle, covered with tarpaulin, in containers or in bulk, or
upon request
Payment & Delivery
1. Both T/T and L/C will be acceptable
2. Trade Terms: FOB, CIF, CFR
3. The delivery will be in 10-15 days if have stock; For customized
items, the delivery will be negotiated by both parties
4. Shipping by sea freight from Shanghai Port (PRC) for Bulk orders, by airfreight or express for samples
Company Information
Shanghai Unite Steel Trading Co., Ltd
We are committed to integrate engineering steel resources in china
and serve the global engineering steel market. Our company has more
than 15 years of experience in steel researching, production,
managing and sales. And our team mostly are based on and worked in
national famous steel enterprise.
In the aspect of resources and information, we have established
cooperative and stronger relationship with nearly hundred
enterprises, either state-owned or private owned in china.
What’s more, we have built long, deep and close business
relationship with dozens of steel company, Sharing and holding
equities with several steel enterprises. Because of the close
cooperation with steel companies and our pioneering spirit, which
can ensure us stay at the top competition, and ensure our customers
get what they really want!
