ASTM A519 GRADE 1045 COLD DRAWN SEAMLESS STEEL PIPING TUBING
OVERVIEW
AISI 1045 Steel is medium tensile steel which exhibits good
weldability, good machinability, and high strength and impact
properties to be used in various industrial applications.
AISI 1045 steel has a low through-hardening capability that
recommended for tempering and through-hardening. This steel shows
reasonable strength and toughness. 1045 is the designation in both
SAE and AISI systems for this material. G10450 is the UNS number.
SAE 1045 Steel is used extensively by all industry sectors for
applications requiring more strength and wear resistance than low
carbon mild steels.
If you are interested in our products, please contact us now for
more detailed information. We assure best in class products with
excellent services to our customers.
APPLICATIONS
AISI 1045 is widely used for all industrial applications requiring
more wear resistance and strength. Typical applications of AISI
1045 are as follows:
| Gears | Pins | Rams |
| Shafts | Rolls | Sockets |
| Axles | Spindles | Worms |
| Bolts | Ratchets | Light gears |
| Studs | Crankshafts | Guide rods |
| Connecting rods | Torsion bars | Hydraulic clamps |
STANDARD SPECIFICATIONS
| Process | Seamless Pipes |
| Shape | Round |
| Size Range | 6-426mm OD |
| Thickness | 1-40mm WT |
| Pipe End | Plain / Beveled / Vanished / Plastic Caps |
| Coating | Black / Galvanised / 3LPE / Turned / Peeled / Grinded / Polished /
Anti – Corrosion Oil |
| Length | 15 Mtr max Cut to Length available |
| Heat Treatment | Spheroidizing / Full Annealing / Process Annealing / Isothermal
Annealing / Normalizing / Quenching / Martempering (Marquenching) /
Quench And Tempering / Austempering |
| Application | Oil & Gas / Hydro Carbon Process / Automotive / Boiler, Heat
Exchanger / Plumbing, HVAC & Firefighting / Structural / General
Engineering / Railways / Sewage & Waterwell |
| Quality Inspection | Third Party inspection is acceptable (SGS, BV etc.) |
TOLERANCE FOR SEAMLESS TUBING
| I.D tolerance (mm) | O.D tolerance (mm) | Straightness (mm) |
| H9-H12 | -/+0.5% | 0.20-0.80 |
Relevant Standard & Grades Equivalency
-ASTM A519 Seamless Carbon and Alloy Steel Mechanical Tubing
-EN 10297-1 Seamless Circular Steel Tubes for Mechanical and
General Engineering Purpose
-DIN1629 Seamless Circular Tubes of Non-alloy Steels with Special
Quality Requirements
-JIS G3444 Carbon Steel Tubes for General Structural Purposes
-JIS G3445 Carbon Steel Tubes for Machine Structural Purposes
Chemical Requirements, Composition, %
| Standard | Grade | C | Mn | P | S | Si |
| ASTM A519 | 1045 | 043-0.50 | 0.60-0.90 | 0.040 | 0.050 | / |
Mechanical properties
| Standard | Steel Grade | Yield strength MPa (>=) | Tensile strength MPa (>=) | Elongation % (>=) | Reduction of area % (>=) | Hardness Brinell |
| ASTM A519 | 1045 | 450 | 585 | 12 | 40 | 163 |
Heat Treatment
Forging
Heat to 850°C - 1250°C (1562°F - 2282°F)
Annealing
Heat to 800°C - 850°C (1472°F - 1562°F)
Normalizing
Heat to 870°C - 920°C (1598°F-1688°F)
Stress Relieving
Heat to 550°C - 660°C (1022°F - 1220°F)
Hardening
Heat to 820°C - 850°C (1508°F - 1562°F)
Tempering
Re-heat to 400°C - 650°C (752°F - 1202°F ) as required
Our Services
What we can offer?
-We offer a wide range of steel products in a wide variety of
dimensions and executions, according to the common international
specifications or customize.
-Machining and heat treatment are available.
-Also, we advise you in choosing the right materials.
Quality Assurance
Below inspection will be done in the production.
(1) ray detection---RT;
(2) ultrasonic testing---UT;
(3) Magnetic Particle Testing-MT;
(4) penetration testing-PT;
(5) eddy current flaw detection-ET
Package
In standard export packing and seaworthy material with hexagon shape bundle, covered with tarpaulin, in containers or in bulk, or
upon request
Payment & Delivery
1. Both T/T and L/C will be acceptable
2. Trade Terms: FOB, CIF, CFR
3. The delivery will be in 10-15 days if have stock; For customized
items, the delivery will be negotiated by both parties
4. Shipping by sea freight from Shanghai Port (PRC) for Bulk orders, by airfreight or express for samples
