E355 Hydraulic Cylinder Steel Tube Cold Drawn Honing Steel Pipe
OVERVIEW
EN 10305 Grade E355 European standard covers technical delivery
conditions for hot formed or annealed hollow sections from
construction steel. EN 10305 Grade E355 Tubes are low-cost Low
Carbon Steel Tubes with max 021 % carbon content with combination
of max 140 % manganese easy to form and shape. Carbon Steel EN
10305 Grade E355 Tubes has a number of other excellent features to
provide like having reliable, superior finish, affordable and more.
Relavent Standard & Grades Equivalency
-EN 10305-1: 2010 Steel tubes for precision applications. Seamless
cold drawn tubes. Technical delivery conditions
-EN 10305-4: 2003 Steel tubes for precision applications. Seamless
cold drawn tubes for hydraulic and pneumatic power systems.
Technical delivery conditions
-EN 10297-1: 2003 Seamless circular steel tubes for mechanical and
general engineering purposes. Non-alloy and alloy steel tubes.
Technical delivery conditions
APPLICATIONS
For Auto industry
For machinery use
Oil Cylinder Tube
Motorcyle shock absorber
Auto shock absorber innder cylinder
Telescopic Cylinders
STANDARD SPECIFICATIONS
| Process | Seamless |
| Shape | Round |
| Size Range | ID.: 30-450mm W.T.:2-40mm |
| Pipe End | Plastic Caps |
| Coating | Anti – Corrosion Oil |
| Length | 12 Mtr max Cut to Length available |
| Heat Treatment | +Cc, +LCc, +SR, +Ad, +N |
| Quality Inspection | Third Party inspection is acceptable (SGS, BV etc.) |
TOLERANCE FOR SEAMLESS TUBING
| I.D tolerance (mm) | O.D tolerance (mm) | Straightness (mm) |
| H9-H12 | -/+0.5% | 0.20-0.80 |
Chemical Requirements, Composition, %
| Standard | Grade | C | Mn | P | S | Si |
| EN 10305 | E355 | 0.22 max | 1.60 max | 0.030 max | 0.035 max | 0.55 max |
Equivalent grades of steel E355 (1.0580) Only for reference!
EU
EN | USA | Germany DIN,WNr | France AFNOR | England BS | Italy UNI | Sweden SS | Poland PN | Czechia CSN | Austria ONORM | Russia GOST | Inter ISO |
| E355 | Gr.65 | 1.0060
E355
St52
St52-3 | E335
ES355
TS-47a
TU526 | CEW5
CFS5
E335
ERW5NKM
ERW5NZF | E335
Fe510 | 1650 | MSt6 | 11600 | St60F | St6sp | Fe590 |
Note: Special steel grade is also available, according to customer
request.
Please specify the steel grade and heat treatment method when
sending the inquiry!
Mechanical properties By EN 10305-1
+C
Tensile Strength: > 640 MPa
Elongation: > 4 %
Ratio Yield strength/Tensile stength: > 0.8
+LC
Tensile Strength: > 580 MPa
Elongation: > 7 %
Ratio Yield strength/Tensile stength: > 0.7
+SR
Yield Strength: > 450 MPa
Tensile Strength: > 580 MPa
Elongation: > 10 %
Outside diameter: > 160 mm ;
Yield Strength: > 420 MPa
Tensile Strength: > 580 MPa
Elongation: > 10 %
+A
Tensile Strength: > 450 MPa
Elongation: > 22 %
Ratio Yield strength/Tensile stength: > 0.5
+N
Yield Strength: > 355 MPa
Tensile Strength: 490 - 630 MPa
Elongation: > 22 %
Outside diameter: < 30 mm ; Wall thickness: < 3 mm ;
Yield Strength: > 345 MPa
Tensile Strength: 490 - 630 MPa
Elongation: > 22 %
Test Methods
Tensile test
Flattening test
Drift expanding test
Dimensional inspection
Roughness measurement
Visual examincation
Not-Destructive Test
a. Test for longitudinal imperfections-
- Eddy current test - EN10246-3, level E3
- ultrasonic testing - EN10246-7, level U3
b. Leak-tightness
- Non-destructive testing for verification of leak-tightness shall
be carried out in accordance with EN10246-1
